Product

Crystal Oscillator

Product > TCXO > Crystal Oscillator
Differential XO
Series Photo Size(L×W×H)[mm]Frequency RangeFrequency StabilityOutput TypeSupply Voltage Data Sheet
3D LVDS SMD 3225 Oscillator 3.2×2.5×0.9510~250MHz±50ppmLVDS2.5V/3.3V
3J LVPECL SMD 3225 Oscillator 3.2×2.5×0.9510~250MHz±50ppmLV-PECL2.5V/3.3V
3H HCSL SMD 3225 Oscillator 3.2×2.5×0.9525~200MHz±50ppmHCSL2.5V/3.3V
5D LVDS SMD 5032 Oscillator 5.0×3.2×1.210~320MHz±50ppmLVDS2.5V/3.3V
5J LVPECL SMD 5032 Oscillator 5.0×3.2×1.210~320MHz±25ppmLVPECL2.5V/3.3V
5H HCSL SMD 5032 Oscillator 5.0×3.2×1.225~200MHz±25ppmHCSL2.5V/3.3V
7B LVDS SMD 7050 Oscillator 7.0×5.0×1.4510~1500MHz±25ppmLVDS2.5V/3.3V
7J LVPECL SMD 7050 Oscillator 7.0×5.0×1.4510~1500MHz±25ppmLVPECL2.5V/3.3V
7H HCSL SMD 7050 Oscillator 7.0×5.0×1.325~200MHz±25ppmHCSL2.5V/3.3V
9D LVDS SMD Crystal Oscillator 14×9×5.625~700MHz±50ppmLVDS2.5V/3.3V
9J LVPECL SMD Crystal Oscillator 14×9.0×5.625~700MHz±50ppmLVPECL2.5V/3.3V
SPXO
Series Photo Size(L×W×H)[mm]Frequency RangeFrequency StabilityOutput TypeSupply Voltage Data Sheet
1N SMD 2016 Crystal Oscillators 2.0×1.6×0.754~54MHz±25ppmCMOS1.8V~3.3V
2N SMD 2520 Crystal Oscillators 2.5×2.0×0.84~75MHz±25ppmCMOS1.8~3.3V
3N SMD 3225 Crystal Oscillator 3.2×2.5×1.01~125MHz±25ppmCMOS1.8~3.3V
7N SMD 5032 Crystal Oscillators 5.0×3.2×1.21~150MHz±20ppmCMOS1.8~3.3V
6N SMD 7050 Crystal Oscillator 7.0×5.0×1.31~170MHz±25ppmCMOS1.8~5.0V
9N SMD 1490 Crystal Oscillator 14×9×5.41~170MHz±25ppmCMOS1.8~5.0V
6MF Full-size Crystal Oscillator 20×13×5.30.25~180MHz±20ppmCMOS3.3V /5.0V
6MH Half-Size Crystal Oscillator 13×13×5.30.25~180MHz±20ppmCMOS3.3V /5.0V
VCXO
Series Photo Size(L×W×H)[mm]Frequency RangeFrequency StabilityOutput TypeSupply Voltage Data Sheet
3S Series SMD 3225 VCXO 3.2×2.5×0.9550~200MHz±25ppmCMOS3.3V
3P LVPECL SMD 3225 VCXO 3.2×2.5×0.9550~200MHz±25ppmLVPECL3.3V
5S SMD 5032 VCXO 5.0×3.2×1.250~200MHz±50ppmCMOS3.3V
5P LVPECL SMD 5032 VCXO 5.0×3.2×1.250~200MHz±50ppmLVPECL3.3V
5V LVDS SMD 5032 VCXO 5.0×3.2×1.250~200MHz±50ppmLVDS3.3V
6S SMD 7050 VCXO 7.0×5.0×1.31~200MHz±25ppmCMOS3.3V/5.0V
7P LVPECL SMD 7050 VCXO 7.0×5.0×1.350~700MHz±50ppmLVPECL3.3V
6V SMD 7050 LVDS VCXO 7.0×5.0×1.350~700MHz±25ppmLVDS3.3V
9S SMD VCXO 14×9.0×5.450~700MHz±50ppmCMOS3.3V
9P SMD LVPECL VCXO 14×9.0×5.450~700MHz±50ppmLVPECL3.3V
9V SMD LVDS VCXO 14×9.0×5.450~700MHz±50ppmLVDS3.3V
6RF Full Size DIP VCXO 20.4×13.1×5.31~80MHz±25ppmCMOS3.3V/5V
6RH Half-Size VCXO 12.8×12.8×5.31~80MHz±25ppmCMOS3.3V/5V
TCXO
Series Photo Size(L×W×H)[mm]Frequency RangeFrequency StabilityOutput TypeSupply Voltage Data Sheet
7X Series SMD 2016 TCXO 2.0×1.6×0.7510~52MHz±2.0ppmClipped Sine wave1.8~3.3V
7Q Series SMD 2520 TCXO/VCTCXO 2.5×2.0×0.810~52MHz±2.0ppmClipped Sine wave1.8~3.3V
7W Series SMD 2520 TCXO 2.5×2.0×0.8510~60MHz±2.5ppmCMOS1.8~3.3V
7T Series SMD 3225 TCXO 3.2×2.5×1.010~60MHz±2.0ppmCMOS1.8~3.3V
8W Series SMD 3225 VCTCXO 3.2×2.5×0.910~52MHz±0.5ppmClipped Sine wave1.8~3.3V
5T Series SMD 5032 VCTCXO 5.0×3.2×1.510~52MHz±0.5ppmCMOS /Clipped Sine wave3.3V /5.0V
8T Series SMD 7050 VCTCXO 7.0×5.0×1.95~52MHz0.05ppmClipped Sine wave /CMOS3.3V/5.0V
9T Series SMD TCXO/VC-TCXO 14.3×8.7×4.95~40MHz0.2ppmClipped Sine wave /CMOS3.3V/5.0V
6T Series 14-Pin TCXO/VCTCXO 20.4×12.8×7.81.25~52MHz±2ppmCMOS /Clipped sine wave2.8V/3.3V
OCXO
Series Photo Size(L×W×H)[mm]Frequency RangeFrequency StabilityOutput TypeSupply Voltage Data Sheet
9X Series SMD OCXO 14.3×9.3×6.55~40MHz±30ppbHCMOS3.3V/5.0V
5X Series SMD OCXO 25.4×22.1×115~40MHz±10ppb Max.HCMOS3.3V/5.0V
2X Series DIP OCXO 20.3×12.7×115~40MHz±50ppbHCMOS3.3V/5.0V
9M Series DIP OCXO 25.4×25.4×12.75~100MHz±3ppbLVTTL/Sine wave3.3V/5.0V/12V
6X Series DIP OCXO 36.3×27.2×12.75~100MHz±5ppbLVTTL/Sine wave5.0V/12V
kHz Oscillator
Series Photo Size(L×W×H)[mm]Frequency RangeFrequency StabilityOutput TypeSupply Voltage Data Sheet
2D 32.768kHz SMD 2520 Oscillator 2.5×2.0×0.832.768kHz±25ppmCMOS1.8~3.3V
3C 32.768kHz SMD 3225 Oscillator 3.2×2.5×0.932.768kHz±25ppmCMOS1.8V~3.3V
5B 32.768kHz SMD 5032 Oscillator 5.0×3.2×1.232.768kHz±25ppmCMOS1.8V~3.3V
7A 32.768kHz SMD 7050 Oscillator 7.0×5.0×1.332.768kHz±25ppmCMOS1.8V~3.3V
