MHz Crystal
Product > Crystal Resonator List > MHz Crystal| Series | Photo | Size / Pins | Frequency Range | Frequency Tolerance | Operating Temperature | Load Capacitance | Data Sheet |
| 6A Crystal Resonator |
|
49U / 2 leads | 1~150MHz | ±20ppm | -20~+70ºC | 12~32pF |
|
| 6B Crystal-Resonator |
|
49S & 49SS / 2 leads | 3.2768~100MHz | ±10ppm | -40~+85℃ | 12~32pF |
|
| 6C Crystal Resonator |
|
49SMD & 49SSMD / 2 pins | 3.2768~100MHz | ±10ppm | -40~85℃ | 12~32pF |
|
| 6P Crystal Resonator |
|
49SSMD Mini / 2 pins | 3.2768~100MHz | ±10ppm | -40~85℃ | 12~32pF |
|
| 6D Crystal Resonator |
|
UM-1, UM-5 / 2 leads | 4~200MHz | ±20ppm | -20~+70℃ | 9~50pF |
|
| 6Z Crystal Resonator |
|
Ø2×6mm Ø3×8mm / 2 leads | 3.579~50MHz | ±10ppm | -20~+70℃ | 12~32pF |
|
| 7S Crystal Resonator |
|
1.2×1.0mm SMD / 4 pins | 36~54MHz | ±15ppm | -20~+70℃ | 6~20pF |
|
| 7Y Crystal Resonator |
|
1.6×1.2mm SMD / 4 pins | 24~54MHz | ±10ppm | -20~+70℃ | 6~32pF |
|
| 7F Crystal Resonator |
|
2.0×1.6mm SMD / 4 pins | 16~96MHz | ±10ppm | -40~85℃ | 6~32pF |
|
| 7E Crystal Resonator |
|
2.5×2.0mm SMD / 4 pins | 12~54MHz | ±10ppm | -40~+85℃ | 8~32pF |
|
| 7U Crystal Resonator |
|
3.2×2.5mm SMD / 4 pins | 8~64MHz | ±10ppm | -40~+85℃ | 8~32pF |
|
| 7I Crystal Resonator |
|
5.0×3.2mm SMD / 4 pins | 8~125MHz | ±10ppm | -40~+85℃ | 10~32pF |
|
| 6J Crystal Resonator |
|
6.0×3.5mm SMD / 2 pins | 8~100MHz | ±10ppm | -40~+85℃ | 10~32pF |
|
| 6G Crystal Resonator |
|
6.0×3.5mm SMD / 4 pins | 8~100MHz | ±10ppm | -40~+85℃ | 10~32pF |
|
| 6F Crystal Resonator |
|
7.0×5.0mm SMD / 4 pins | 6~160MHz | ±10ppm | -40~+85℃ | 16~32pF |
|
| 7Z Glass Crystal |
|
2.5×2.0mm SMD / 4 pins | 12~64MHz | ±10ppm | -20~+70℃ | 8~32pF |
|
| 7V Glass Crystal |
|
3.2×2.5mm SMD / 2~4 pins | 8~64MHz | ±10ppm | -40~+85℃ | 8~32pF |
|
| 6I Glass Crystal |
|
5.0×3.2mm SMD / 2~4 pins | 8~64MHz | ±10ppm | -40~+85℃ | 10~32pF |
|
